GNSS characteristics
■692 GNSS channels
-GPS L1C/A, L1C, L2C, L2E, L5
-GLONASS L1C/A, L2C/A, L2P, L3
-BeiDouB1, B2, B3
-Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B
-SBAS L1C/A, L5
■Initialization: time <10s, reliability >99.99%
■Supported data formats:
CMR+, CMRx, RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2
■Output data formats:
NMEA 0183, PJK plane coordinates, Binary code, Trimble GSOF
Positioning Accuracy
Code differential GNSS positioning
■Horizontal: ±0.25m+1ppm
■Vertical: ±0.50m+1ppm
■SBAS positioning accuracy: typically<5m 3DRMS
Static
■Horizontal: ±2.5mm+0.5ppm
■Vertical: ±5mm+0.5ppm
Real-time kinematic (RTK)
■Horizontal: ±8mm+1ppm
■Vertical: ±15mm+1ppm
Network RTK
■Horizontal: ±8mm+0.5ppm
■Vertical: ±15mm+0.5ppm
RTK initialization time
■2~8s
Physical characteristics
Size
■17.5 x 17.5 x 8.3 cm
Weight
■1.33 kg (2 batteries included)
User interface
■Five Indicator lights
■Two buttons
■Linux System
I/O interface
■5PIN LEMO external power port+RS232
■7PIN external USB(OTG)+Ethernet
■Bluetooth 2.1+EDR standard
■Bluetooth 4.0 standard, support android, iosconnection
Memory
■8GB SSD internal storage
■Support external USB storage (up to 32 GB)
■Automatic cycle storage
■Changeable record interval
■Up to 50Hz raw data collection
Operation
■RTK rover & base
■RTK network rover: VRS, FKP, MAC
■NTRIP, Direct IP
■Post-processing
Environmental characteristics
■Operating temperature: -45°to +60°C
■Storage temperature: -55°to +85°C
■Humidity: 100% condensing
■IP67 waterproof, sealed against sand and dust
■Drop: 2m pole drop on concrete
Power characteristics
■Two Li-Ion batteries, 7.4 V, 3400 mAh
■Battery life:>14h (static mode)>10h (internal UHF base mode)>12h (rover mode)
■External DC power: 9-25 V
UHF Radio characteristics
■Built-in radio
■Frequency Range 410-470MHz
■Protocol:TrimTalk450s, TrimMark3, SOUTH (KOLIDA)
■1W/2W/3W switchable
■typically working range 7-8km
■“Barrier-Free” Measurement Technology: Repeater/ Router/ CSD mode
Cellular module characteristics
■WCDMA/CDMA2000/TDD-LTE/FDD-LTE 4G
■Compatible with 3G GPRS/EDGE
WebUI
■Configure and monitor receiver by web server via Wi-Fi or USB cable
NFC
■Close range (shorter than 10cm) automatic pair between receiver and controller (need NFC chip in controller)
Wifi
■802.11 b/g standard
■Hotspot: allow device to access in
■data link: broadcast differential data
Voice Guide
■intelligent voice technology provides status indication and operation guide
■Chinese, English, Korean, Russian, Portuguese, Spanish, Turkish and user define
Standard system components
■K5 UFO Receiver
■Li-Ion battery
■Charger and adapter
■All-direction antenna
■Tape measure
■30 cm pole extension
■7-pin to OTG cable
■Engineering Star (Windows)
■Engineering Star (Android)
■1 year warranty
Optional system components
■External Radio (410-470 MHz, 5-35W)
■Battery Case SA-6003
■Data collectors
-K720 (Windows)
-H3 plus (Android)-T17 (Windows)
-X11 pro (Windows)
■Field software
-Field Genius (Windows)-SurvX(Android)
■1-2 year warranty extension |
